CE IP65 3 YR WARRANTY

600 W Modular LED Flood Light

SKU JNFLM20-600S-6500-A8-ND

600W modular LED flood light, 2×4 module config, Philips Lumileds (Luxeon TX), Meanwell drivers. Replaces 1000W MH/HID/HPS. IP65.

OUTPUT

1,200 lm

POWER

600 W

INGRESS

IP65

BEAM

140×140°

Project pricing on request

Volume, vessel class and coating affect price. Engineers reply within 48 h.

Technical specification

Product SKU	JNFLM20-600S-6500-A8-ND
Power Consumption	600 W
Kelvin (K)	2000
Color Rendering Index (CRI)	70+
Beam angle (°)	140×140°
IP Rating (Ingress Protection)	IP65
Dimming Capability	Non-dimmable
Certifications	CE, RoHS
Housing colour	Black
Kelvin	Cool White
Input Voltage	100–240 V
Input Frequency	50/60 Hz
LED type	Philips Lumileds (Luxeon TX)
Product Subtype	Floodlight
Power Factor (PF)	>0.95
Total Lumen output	1200
Warranty period (Years)	3
Housing material	Aluminum
System Power	600 W
Number of LED Modules	4 modules
Beam Angle Square	30°×60°
Environmental Temperature Range	-30°C to +50°C
Mounting Type	Bracket Mount
Fixture height (mm)	681 mm
Fixture length (mm)	328 mm
Fixture width (mm)	113 mm
Product Weight	17.2 kg
LED driver brand	Meanwell
IK impact rating	IK04

Product dimensions (mm)	681 × 328 × 113 mm (depth with fully extended bracket: 203 mm)
Net weight (kg)	17.2 kg
Export carton dimensions (mm)	750 × 490 × 190
Products per carton	1
Export carton gross weight (kg)	19.2 kg

1,200 lm

TOTAL OUTPUT

600 W

POWER DRAW

140×140°

BEAM
