IP44
Horizontal Bend Neon Flex Recessed 17 x 20mm 10W/m 24V Orange IP44
SKU JN-NF-10W-Orange-17*20S-Hor
Horizontal Bend Neon Flex Recessed: 17 x 20mm, Horizontal (Recessed), Mono Colorful, 10W/m, DC24V, Orange, IP44.
OUTPUT
167 lm/m
POWER
10W/m
INGRESS
IP44
BEAM
Orange
Project pricing on request
Volume, vessel class and coating affect price. Engineers reply within 48 h.
Technical specification
| Product SKU | JN-NF-10W-Orange-17*20S-Hor |
|---|---|
| Power Consumption | 10W/m |
| Input Voltage | 24V DC |
| Kelvin (K) | Orange |
| Color Rendering Index (CRI) | >90 |
| IP Rating (Ingress Protection) | IP44 |
| Bending Type | Horizontal (Recessed) (min Ø150mm) |
| Dimension (W×H) | 17 x 20mm |
| Photometric Type | Mono Colorful |
| Colour Range | 605-615nm |
| Cut Point (mm) | 50mm |
| Lumen Output (lm/m) | 167 lm/m |
| Input Current Per Meter | 0.42A/m |
| Max Run Length (m) | 5 |
| Circuit Type | CV |
| Working temperature range | -20°C ~ 50°C |
| Lifespan (hours) | 50,000 hours |
| Product dimensions (mm) | 5000x17 x 20mm |
|---|
Performance
167 lm/m
TOTAL OUTPUT
10W/m
POWER DRAW
Orange
BEAM
