IP67
Neon Flex 04*08 Horizontal Bend 4 x 8mm 6W/m 24V Yellow
SKU JN-NF-6W-Yellow-04*08S-Hor
Neon Flex 04*08 Horizontal Bend: 4 x 8mm, Horizontal, Mono Colorful, 6W/m, DC24V, Yellow, IP67.
OUTPUT
55 lm/m
POWER
6W/m
INGRESS
IP67
BEAM
Yellow
Project pricing on request
Volume, vessel class and coating affect price. Engineers reply within 48 h.
Technical specification
| Product SKU | JN-NF-6W-Yellow-04*08S-Hor |
|---|---|
| Power Consumption | 6W/m |
| Input Voltage | 24V DC |
| Kelvin (K) | Yellow |
| Color Rendering Index (CRI) | >90 |
| IP Rating (Ingress Protection) | IP67 |
| Bending Type | Horizontal (min Ø30mm) |
| Dimension (W×H) | 4 x 8mm |
| Photometric Type | Mono Colorful |
| Colour Range | 585-595nm |
| Cut Point (mm) | 50mm |
| Lumen Output (lm/m) | 55 lm/m |
| Input Current Per Meter | 0.25A/m |
| Max Run Length (m) | 5 |
| Circuit Type | CV |
| Working temperature range | -20°C ~ 50°C |
| Lifespan (hours) | 50,000 hours |
| Product dimensions (mm) | 5000x4 x 8mm |
|---|
Performance
55 lm/m
TOTAL OUTPUT
6W/m
POWER DRAW
Yellow
BEAM
